Q235 Carbon Steel Galvanized Steel Pipe With Hot Rolled Process Galvanized

MOQ: 100 Meter

Delivery time: 15 Day

Product Details

Product Details:

Place of Origin:	China
Brand Name:	Gangyu Pipeline
Certification:	ASME/GB/EN/JIS/IS
Model Number:	1 1/2''

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	negotiable
Packaging Details:	Strapped in bundles
Delivery Time:	10 working days after received your payment
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50,000tons per month

Product Name:	Galvanized Pipe	Connection:	Plain Ends
Shape:	Round	Material:	Q235
Techniques:	Hot Dip Galvanized	Wall Thickness:	SCH40
Standard:	ASME/GB/EN/JIS/IS	Size:	1 1/2''

Q235 material hot rolled process galvanized carbon steel pipe

ERW galvanized steel pipe are produced using the cold drawn or hot rolled process. erw galvanized steel pipe are manufactured from carbon and alloyed steel. erw galvanized steel pipe are practically used in all areas of the machine production, for example: automobiles, motorcycles, electric cars, bearings, ships and pneumatic components etc.

Material	Chemistry Composition %
Material	C	Si	Mn	S	P	Cr
10	0.07-0.13	0.17-0.37	0.35-0.65	≤0.035	≤0.035
20	0.17-0.23	0.17-0.37	0.35-0.65	≤0.035	≤0.035
35	0.32-0.39	0.17-0.37	0.35-0.65	≤0.035	≤0.035
45	0.42-0.50	0.17-0.37	0.50-0.80	≤0.035	≤0.035
40Cr	0.37-0.44	0.17-0.37	0.50-0.80	≤0.035	≤0.035	0.08-1.10

Galvanized Steel Pipe Size:

Outer Diameter		Wall Thickness	Length
Inch	mm	mm	meter
1/2"	21.3mm	0.6mm-3.0mm	0.3m-12m
3/4"	26.9mm	0.6mm-3.0mm	0.3m-12m
1"	33.4mm	1.0mm-3.0mm	0.3m-12m
1-1/4"	42.3mm	1.0mm-4.0mm	0.3m-12m
1-1/2"	48.3mm	1.0mm-4.0mm	0.3m-12m
2"	60.3mm	1.5mm-4.0mm	0.3m-12m
2-1/2"	76.1mm	1.5mm-4.0mm	0.3m-12m
3"	88.9mm	1.5mm-9.5mm	0.3m-12m
4"	114.3mm	2.0mm-9.5mm	0.3m-12m
5"	141.3mm	3.0mm-9.5mm	0.3m-12m
6"	168.3mm	3.0mm-12.0mm	1.0m-12m
8"	219.1mm	3.2mm-12.0mm	1.0m-12m
10"	273mm	3.2mm-12.0mm	1.0m-12m
12"	323.8mm	6.0mm-15.0mm	1.0m-12m
14"	355.6mm	8.0mm-15.0mm	1.0m-12m
16"	406.4mm	8.0mm-20.0mm	1.0m-12m

Commodity	Items	Standard	Steel grade	O.D.&W.T. range
Tubes for Structural Purposes & Ordinary Pipe	Square steel tube	GB/T 3091	Q195,Q215,Q235,Q345 GR.A, GR.B, GR.C St37,st52 S235JRH,S355J0H	(2020-500500mm)X (1-16mm)
		GB/T 6728
		JIS G 3444
		ASTM A513
		ASTM A500
	Rectangular steel tube	BS 1387		(2030-450500)*(1-20mm)
	Rectangular steel tube	EN 10219		X 1.0mm-16mm
	Round pipe	ASTM A53		1/2inch-24inch
	Round pipe	BS EN 10025		X 1.0mm-30mm
Hot-dip Galvanized Pipe	Round	BS 1387	Q195,Q215,Q235,Q345 GR.A, GR.B, GR.C St37,st52 S235JRH,S355J0H	(1/2’’-12’’)*(1.5-12mm)
		ISO 65
		ASTM A53
		EN 10240
	Square and Rectangular	GB/T 3091		(2020-500500mm) X( 1-16mm )
